Basic Instructions:

If your timer has changed due to a  black out or from any other electrical change do the following :

Setting the Time of Day:

-SXT Valves (blue led light with black numbers)

  1. Press and hold either the Up or Down buttons until the programming icon replaces the service icon and the parameter display reads TD.
  2. Adjust the displayed time with the Up and Down buttons (PM indicated when pm icon appears near time display).
  3. When the desired time is set, press the Extra Cycle button to resume normal operation. The unit will also return to normal operation after 5 seconds if no buttons are pressed.

-SE Valves (Red LED display)

  1. Whenever valve is ‘in service’ the current time of day can be set
    Use Up/Down buttons to set time to current time of day (PM indicated with dot in lower right corner).

*When Time of Day is set to correctly unit will flush at programmed time.
* Unit Bypass valves and their operation are described in Service Manual (Click on service manual icon above).
*If you receive an error message on screen unplug unit form power supply, wait 15 seconds , plug back in. This will reset the computerized valve.

Most issues can be resolved by phone within a few minutes. For more details , please refer to the user manual.

Clack Control Valve Reset

When Err 1 flashes on Clack WS1 do the following:

  1. Remove the faceplate of the control valve
  2. Remove the right white clip from its holder
  3. Wait 30 seconds
  4. Plug it back in, you should see time and date.

Clack Control Valve Reset   Clack Control Valve Reset

Click Here to Download the
Superior Water User Manual
